【Xhorse Official Blog】CONDOR XC-MINI Plus

CONDOR XC-MINI Plus

Automatic Key Cutting Machine

Find out the latest news from Xhorse on Twitter and YouTube↓↓↓

Twitter @XhorseGlobal

YouTube Xhorse Global

Instagram XhorseGlobal

1. PN Information

DOLPHIN XP-005 -- PN: XCMNP0EN

Power 200W
Input Frequency 47~63Hz
USB Port USB 2.0
Working Voltage 90-264V/AC
Working temperature -20~50℃
Working Humidity 10%~90%
Motor Rotation Speed 9000rpm
Machine Dimension 250×413×300mm
Package Dimension 515×480×380mm
Net Weight 20kg
Gross Weight 22.9kg
LED Dsiplay 1024×600
3. Main functions

Multi-functional Clamps
Standard equipped with two clamps M1 and M2 with clear identification. Clamp M1 and Clamp M2 support Sided, Track, and Dimple keys.
Two Optional Clamps M3 and M4 with clear identification need to be purchased separately. Clamp M3 supports some Dimple/Tibbe keys especially for Ford FO21&Citroen SX9 keys. Clamp M4 supports the side-opening keys and the cross keys.
Standard Equipped: Clamp M1, Clamp M2
Optional: Clamp M3, Clamp M4

All-aluminum body structure, lightweight and easy to carry;
Partial components of the machine made of stainless steel enable the whole machine body more stable and reliable;
Equipped with 3-Aixs Precision Ball Screw Transmission possesses precise and stable function better than the T Screw transmission

Built-in accurate database, detailed parameters, and key graphics enable all the users to choose the right blank key to edit its shape, space, width, and depth to generate user-defined key functions.
The database will be updated soon to bring convenience to more users.

Adopting international general full range AC (Alternating Current) input (90V-264V);
Working efficiency up to 93%;
Able to sustain surge voltage input(300V) for up to 5 seconds;
No-load loss power lower than 0.5 Watt;
Built-in 200V brushless motors;
High rotation speed; Low noise, Minimal vibration;
Strong reliability and great stability.

CONDOR XC-MINI Plus Automatic Key Cutting Machine has Appearance Patent Certificate, Computer Software Copyright Registration Certificate, Utility Model Patent Certificate, etc.

CONDOR XC-MINI Plus Automatic Key Cutting Machine supports free software upgrade service(include software, hardware, and database)

CONDOR XC-MINI Plus Automatic Key Cutting Machine provides the powerful functions for all key lost: constantly updated key database, cut by bitting and find bitting. It is perfectly a right tool for locksmiths to recover easier from All Key Lost.
