Wanna know more about VVDI remotes? Today we are gonna show you a variety of quick tips on how to use our remotes, which can effectively help your work.

🔸Detect Remote🔸

There are many types of VVDI remotes, and here's one way that's going to help you distinguish them quickly.

Use the Xhorse generation device such as MINI KEY TOOL and connect the device to your smartphone.

Tap 'Special Function', go to 'VVDI remote function' and then select 'Detect Remote'.


Place the remote and start detecting and it will show all the information of the remote.



🔸Points Collection🔸

After generating the remote, return to the home page and tap the red button 'More' to collect bonus points.

Please note that points are only available for the first successful generation.

Generating wired remotes will give you 25 points.

Generating wireless remotes and super remotes will award you with 40 points.

Generating universal smart keys will give you 60 points.

But there is no point for dedicated remote generation.

For example, generating an XM38 TOY.T smart key won't generate any points.

🔸Query remote usage record🔸

Tap 'Special Function' - 'VVDI remote function' - 'Query remote usage record'.

Place the remote as shown and then you can query the usage record of the remotes, including when the points were collected, when the remote was generated and which option it was previously generated to.



🔸VVDI Smart Key Clone🔸

Tap 'Special Function' - 'VVDI remote function' - 'VVDI smart key clone'.

This function is used when exchanging remotes without key learning.

For example, you want to use the KE.LEL universal smart key to generate the remote type which the Knife Style universal smart key uses.

Then you could read the data of the matched Knife Style universal smart key.

After reading successfully, place the KE.LEL universal smart key into the coil and tap 'Clone'.

Wait for the write to succeed, at which point the KE.LEL universal smart key will be used directly without matching.

NOTE: Two keys cannot be used at the same time, otherwise their signals will interfere with one another, which may lead to control failure.

If you need to make two keys, both keys will need to be matched.

🔸Smart Key Customization🔸

Tap 'Special Function' - 'VVDI remote function' - 'Smart key customization'.

Let's take a Knife Style universal smart key as an example. Its Lock button and Unlock button are opposite, and the Trunk button is invalid.

Read the data and you can see that the Lock value is 04 and the Unlock value is 01.

Then you just need to change the Lock value to 01 and the Unlock value to 04.

Tap 'Setting'.

After writing successfully, read again and you can see the Lock and Unlock buttons have been adjusted properly.

Next, solve the problem of the invalid Trunk button.

Now the value of the Trunk is 08.

And the common values include 01, 02, 04, 08, 10, 20, 40, 80, 0A, 0B, 0C and 0D.

Try to input these values one by one. Perform a test after each input until the trunk key is valid. If all values are invalid, please contact our technical support on the Xhorse App and we will do our best to help you.
